Rail Material Handling Turntable which can turn to 360 degrees for warehouse to rotate a trailer

Name: Rail Material Handling Turntable which can turn to 360 degrees for warehouse to rotate a trailer
Brand: Material Handling Turntable
Price: 3000 USD

Quality Rail Material Handling Turntable which can turn to 360 degrees for warehouse to rotate a trailer wholesale

Brand Name : Material Handling Turntable

Model Number : Material Handling Turntable

Certification : CE ISO SGS

Place of Origin : Henan China

MOQ : 1

Price : USD3000-6000/set

Payment Terms : L/C, T/T

Supply Ability : 30sets/week

Delivery Time : 20 work days after received balance payment

Packaging Details : Trap and wooden case

Material : Q235

Battery Voltage(v) : 24-72

Product name : material handling equipment in warehouse motorized turntable heavy duty custom material handling carts

Capacity : 5-40t

Type : Material Handling Turntable

Wheel Diameter(mm) : 270-600

Rail Inner Gauge(mm) : 1200-2000

Battery Capacity(Ah) : 180-600

Contact Now

Rail Material Handling Turntable which can turn to 360 degrees for warehouse to rotate a trailer

The Rail Material Handling Turntable which can turn to 360 degrees for warehouse to rotate a trailer is installed in the position where the two rails are crossed, one or more rails are laid on its table. The upper surface of the truntable rails as same high as the upper surface of the track on the ground, and also has the same rail gauge.The Rail Material Handling Turntable which can turn to 360 degrees for warehouse to rotate a trailer is a kind of handing system ,which can make the rail car turn 90 degree on rails .Principle:material handling equipment runs on the turntable ,which will automatically rotate or manually rotate to realize the joint with vertical rails .After turnable rotating ,the material handling equipment can run along the vertical rails .The handing solution can be applied in the occasion such as ring rails ,etc. The turnable system runs steadily and has the features such as high rail jointing accuracy and can meet full automatic electrical control.

Main Components

Advantage
1.High accuracy of rail connection.
2.Totally automatically operated.
3.Convenient and flexible.
4.Control panel with wire or romote control.

5.The Rail Material Handling Turntable is installed in the position where the two rails are crossed, one or more rails are laid on its table.

6.Can make the material handling equipment turn 90 degree on rails.

7.Material handling equipment can run along the vertical rails.

8.Get rid of the track turning problem.

Technical parameters

Model			2t	20t	50t	100t	150t
Rated Load(t)			2	20	50	100	150
Table Size(mm)	Length(L)	2000		4000	5500	6500	10000
	Width(W)	1500		2200	2500	2800	3000
	Heigth(H)	450		550	650	900	1200
Wheel Base(mm)			1200	2800	4200	4900	7000
Rail Inner Gauge(mm)			1200	1435	1435	2000	2000
Wheel Diameter(mm)			270	350	500	600	600
Wheel Quantity			4	4	4	4	8
Ground Clearance(mm)			50	50	50	75	75
Running Speed(min)			0-25	0-20	0-20	0-20	0-18
Motor Power(kw)			1	2.2	5	10	15
Running time When Full Load			4.32	4	3.3	3.2	2.9
Running Distance for Once Charge(KM)			6.5	4.8	4	3.8	3.2
Reference Weight(t)			2.8	5.9	8	14.6	26.8
Recommended Rail Model			P15	P24	P43	QU100	QU100
Max Wheel Load(KN)			14.4	77.7	174	343.8	265.2
Battery Voltage(v)			24	48	48	72	72
Battery Capacity(Ah)			180	180	330	440	600

The scheme

Application

Rail Material Handling Turntable which can turn to 360 degrees for warehouse to rotate a trailer
