Steel Trackless Automated Workshop Bogie For Steel Beam Transport

Brand Name : PERFECT

Model Number : BWP

Certification : CE, SGS, ISO

Place of Origin : Xinxiang, China

MOQ : 1 Set

Payment Terms : L/C, T/T, Western Union

Supply Ability : 75 Sets per month

Delivery Time : 45 Days

Packaging Details : The body will be packed with tarp, and other parts will be packed with wooden cases.

Product Name : Steel Trackless die transfer cart

Powered Source : Storaged Battery

Rail Gauge : 1435mm, Customized

Cart Frame : Q235B

Load Capacity : 1-200T (Customized)

Color : Yellow/Customized

Working Time : 6~7 Hours

Wheel Type : Polyurethane Coated Wheel

Safrty Device : Buffer, Alarm light, Emergency Stop Buttons

Special Function : Anti-Explosion, Heat-Resistant, Lifting, Dumpling

Contact Now

Steel Trackless Automated Workshop Bogie for Steel Beam Transport Automated Workshop Bogie for

Introduction of Steel Trackless Die Transfer Cart

Henan Perfect Handling Equipment Co., Ltd offers a wide range of automated workshop bogie specifically designed for the unique needs of stamping, molding, heavy die, bulk cargos, foundry and many other heavy duty things transporting or mold from die storage to the press line.
The body of the automated workshop bogie is made of thick steel plate and with super anti-distortion performance. All the bogies are equipped with warning alarm and security detection devices, and the alarm would ring and the car would stop immediately once there was any obstacle or pedestrian in the running path of the automated workshop bogie.

Application of Automated Workshop Bogie

PERFECTautomated workshop bogies are operating in many shipping lines, stevedores, concrete manufacturers, foundries, steel mills, etc. We have supplied hybrid automated workshop bogies in the world for moving molds inside and outside the plant by electric traction and driving long distances.And also automated workshop bogies are mainly used to solve manoeuvrability problems in tight spaces. Due to all possible steering programs, on either one or different axles, you can achieve tight turning radious. The propulsion can be either electric for in-plant load carts or batteries for long distances.

Parameters of Steel Trackless Die Transfer Cart

Model BWP-5t BWP-20t BWP-30t BWP-40t BWP-50t
Rated Load(t) 5 20 30 40 50
Impacted rated load(t) 5 20 30 40 50
Structure of Frame Steel plates welded, beam
thickness of the steel plate 8 14 14 16 16
Cart weight(t) 4.3 7.9 8.8 10 10.5
Max. wheel load (t) 2.8 5.6 7.7 10 12
Ground requirement Cement floor or Steel plate ground
Ground Clearance(mm) 50 50 50 50 50
Table size (mm) 3000*2000 4500*2200 5000*2200 5500*2300 6000*2300
Height of the whole cart (mm) 450 600 650 700 700
Wheel base (mm) 1500 1700 1700 1800 1800
Axles distance (mm) 2500 3900 4300 4800 5200
Turning radius (mm) 2501 3901 4301 4801 5201
Turning type Turning while driving with no stop
Control method for turning Control button
Turning structure Mechanical
Motor power (KW) 3.5 7 10 12 15
Wheel diameter (mm) 300 (4) 400 (4) 400 (6) 500 (6) 500 (6)
Wheel material ZG55+hydropurture
Running speed (m/min) 0-15 0-12
Brake principle Electric magnetic brake
Ground balance mechanical automatic adjustment
Operation method With wire or no wire
Battery model D-250 24pieces D-440 24pieces D-250 36pieces D-330 36pieces D-440 36pieces
Battery maintenance Free of maintenance
Charger's installation Installed on cart Split-type
Cart color Yellow and warning sign
Charger's function Automatic stop for obstacles
Radar control 3-0.3 m, Automatic stop for obstacles
Warning equipment Sound and light
Other functions Turning light, night light and power display

Packing and Shipping

The body of the cart is packed with tarp, the small parts will be packed with wooden cases. According the table size and quantity, the cart would be carefully fixed and transported by FCL, LCL, Bulk Transportation, Open Top Container, Flat Rack Container and so on.
