Custom Battery Steel Coil Trolley In Railway Transportation For Warehouse

Brand Name : PERFECT

Model Number : BXC

Certification : CE, SGS, ISO

Place of Origin : Xinxiang, China

MOQ : 1

Payment Terms : L/C, T/T, Western Union

Supply Ability : 75 Sets per month

Delivery Time : 45 Days

Packaging Details : The whole cart is package with tarp, and parts will be packed by wood case

Powered Source : Storage Battery / Lead-acid Battery

Operation Mode : Pandent and Remote Controller and PLC

Cart Frame : Q235B

Rail Gauge : 1435mm (Customized)

Color : Yellow/Customized

Running Distance : No Limited

Wheel Type : Cast steel wheel

Safrty Device : Buffer, Alarm light, Emergency Stop Buttons

Special Function : Anti-Explosion, Heat-Resistant, Lifting, Dumpling

Dimension : Customized

Contact Now

Custom Battery Steel Coil Trolley in Railway Transportation for warehouse

Introduction for Electric Railway Platform

Our steel coil trollies are used to transport steel coils and pipes for metal industry. These coil transfer Cars are designed to be an extremely cost effective, safe and flexible load moving alternative.The steel coil trolley is also called a heavy transporter, headless transporter or self-propelled modular transporter. Our steel coil trolleies are specially designed for coil, pipe and other round material transportation. When the goods are loaded, we can make sure the car moves safely and the goods are in a very safe condition.

Applications for cart

For horizontal load transfers of a wide range of material, we have the heavy duty, high quality Transfer Cart solution you need. Transfer carts are used: to carry loads along assembly lines; transfer material from one work station to the next; store and transport an entire shift worth of production. They can even be used as a stable yet moveable machine base. With four different styles and standard capacities up to 60 tons, we have the solution you need and each style can be designed for your specific application.

Characters of Electric Railway Platform

  • Anti-explosion
  • Anti-high temperature
  • Suitable for ferry condition
  • Apply to various occasions
  • Stable start, big starting power, small impact to the gear reducer, low voltage, long lifetime and so on.
  • It has no strict requirement for the construction of the railway
  • No limit of moving distance
  • Safe and convenient operation for there is no wire outside the car
  • Adjustable speed

Technical Parameters

BXC SERIES TRANSFER CART TECHNICAL PARAMETER TABLE
Model BXC-2t BXC-20t BXC-50t BXC-100t BXC-150t
Rated Load(t) 2 20 50 100 150
Table Size (mm) Length(L) 2000 4000 5500 6500 10000
Width(W) 1500 2200 2500 2800 3000
Height(H) 450 550 650 900 1200
Wheel Base(mm) 1200 2800 4200 4900 7000
Rail Inner Gauge(mm) 1200 1435 1435 200 2000
Wheel Diameter(mm) 270 350 500 600 600
Wheel Quantity 4 4 4 4 8
Ground Clearance(mm) 50 50 50 75 75
Running Speed(min) 0-25 0-20 0-20 0-20 0-18
Motor Power(kw) 1 2.2 5 10 15
Battery Capacity 180 180 330 440 600
Battery Voltage 24 48 48 72 72
Running Time When Full Load 4.32 4 3.3 3.2 2.9
Running Distance for One Charge(Km) 6.5 4.8 4 3.8 3.2
Max Wheel Load(KN) 14.4 77.7 174 343.8 265.2
Reference Weight(t) 2.8 5.9 8 14.6 26.8
Recommended Rail Model P15 P24 P43 QU100 QU100

Why choose us?

Currently, our coil transfer carts not only have been sold in China, but also exported to American, Germany, Thailand, Holland, Turkey South Africa, Nepal, etc. We are becoming more and more popular around the world and get high evaluations from our cooperators.
We have been specializing in transfer cart manufacture for over 15 years.With advanced equipment,excellent engineers and professional workers, we have got the certificates of CE, SGS, ISO. Our products can be used in industrial,steel,pharmacy,mining and many other lines. So we can assure that we will provide high quality and cost-effective products for you.
